ROMP · SKC series
SKC Series | General-Purpose Rigid Casters
Imported from Japan, the nansin SKC series of general-purpose rigid casters is suitable for factory equipment, household items and transport equipment. The specifications on this page cover wheel diameters of 25–75 mm. Select a variant to suit your wheel material, load capacity and mounting requirements.
Features
Imported nansin casters from Japan
The SKC series offers general-purpose rigid casters with wheel diameters and materials to suit your equipment mounting requirements.
Multiple wheel materials
Options include TP rubber, rubber, hard rubber, elastomer, nylon and polyurethane wheels. See the table below for the materials available at each wheel diameter.
Wheel diameters: 25–75 mm
The catalog specifications on this page cover 25, 32, 38, 50, 65 and 75 mm wheel diameters. Load capacities range from 8 to 82 kgf, depending on wheel diameter and material.
Smooth rolling with rubber wheels
Rubber wheels offer high resilience for smooth rolling with less effort. This feature applies to rubber wheel options.
Applications
Factory equipment, household items, transport equipment, carton pallets and furniture.
Specifications
Swipe left or right to view all specifications. The model column stays fixed on the left for easy row-by-row comparison.
| Model – Wheel Diameter | Wheel Code | Wheel Material | Load Capacity | Initial Rolling ForcedaN | Wheel Diameter Dmm | Wheel Width Wmm | Mounting Height Hmm | Mounting Hole Spacing A×B (A′×B′)mm | Top Plate Size X×Ymm | Mounting Hole Diameter Pmm | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| N | kgf | ||||||||||
| SKC-25 | EM | Gray TP rubber | 80 | 8 | 0.48 | 25 | 13 | 35 | 29 (2 holes) | 37×19 | 4.2 |
| SKC-25 | NM | White nylon | 100 | 10 | 0.90 | 25 | 13 | 35 | 29 (2 holes) | 37×19 | 4.2 |
| SKC-32 | EM | Gray TP rubber | 120 | 12 | 0.72 | 32 | 14 | 42 | 29 (2 holes) | 37×19 | 4.2 |
| SKC-32 | NM | White nylon | 180 | 18 | 1.62 | 32 | 14 | 42 | 29 (2 holes) | 37×19 | 4.2 |
| SKC-38 | EM | Gray TP rubber | 200 | 20 | 1.20 | 38 | 18 | 50 | 36×15 | 46×25 | 5.3 |
| SKC-38 | NM | White nylon | 280 | 29 | 2.52 | 38 | 18 | 50 | 36×15 | 46×25 | 5.3 |
| SKC-50 | EM | Rubber | 500 | 51 | 10.50 | 50 | 21 | 65 | 45×25 | 58×44 | 6.5 |
| SKC-50 | TP | Elastomer | 500 | 51 | 4.73 | 50 | 20 | 65 | 45×25 | 58×44 | 6.5 |
| SKC-50 | NM | White nylon | 600 | 61 | 6.30 | 50 | 20 | 65 | 45×25 | 58×44 | 6.5 |
| SKC-65 | EM | Rubber | 500 | 51 | 10.50 | 65 | 25 | 85 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-65 | EMH ▲ | Hard rubber | 500 | 51 | 14.40 | 65 | 25 | 85 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-65 | TP | Elastomer | 500 | 51 | 6.00 | 65 | 27 | 85 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-65 | NM | White nylon | 700 | 71 | 7.35 | 65 | 25 | 85 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-65 | GNU | Polyurethane | 700 | 71 | 10.50 | 65 | 25 | 85 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | EM | Rubber | 600 | 61 | 12.60 | 75 | 25 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | EMB | Rubber (with bearing) | 600 | 61 | 9.00 | 75 | 25 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | EMH ▲ | Hard rubber | 600 | 61 | 14.40 | 75 | 25 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | NRC | Gray rubber (with bearing) | 600 | 61 | 3.60 | 75 | 25 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | TP | Elastomer | 500 | 51 | 9.90 | 75 | 27 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | NM | White nylon | 800 | 82 | 8.40 | 75 | 25 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | NTB | Polyurethane (with bearing) | 800 | 82 | 4.80 | 75 | 25 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
| SKC-75 | GNU | Polyurethane | 800 | 82 | 12.00 | 75 | 27 | 93 | 55×28 (54×28) | 70×52 | 8.8 |
▲ indicates made-to-order products; please contact us for ordering conditions. “B入” in the catalog denotes a wheel with a bearing. The brackets are chrome-plated. Dimensions in parentheses indicate the alternative mounting hole spacing listed in the catalog.
